Quick overview of E2E testing in Angular

This article assumes that you use the angular-cli, and have basic knowledge on how it works.

What is End-to-End testing?

While unit tests helps you find bugs, there are some things that won’t be noticeable at this level. That is where e2e or integration tests comes in, where you automate a user using your application in one or more browsers.

As our applications grow in size, testing the correctness of the  UI (user interface) manually becomes unrealistic and tedious. It also helps you find out if certain parts of the UI, stops working as expected.

Getting started

Your tests are located in the e2e folder in the root directory of your project

A test is contained within a spec or specification file. The spec file for the e2e tests have to end with .e2e-spec.ts. Else ng e2e won’t find your tests.

You can think of a spec as a scenario that a user acts out.
An example would be:

  1. A user wish to login,
  2. go to their profile page
  3. change password.

Your tests are ran per spec file alphabetically, then in order of your tests

assessment of all patients presenting with this complain.first line treatment for the majority of patients because of buy viagra online.

. If you wish to run, lets say a login test first add _ as prefix.

Protractor config

Protractor allows you to define several browsers that you wish to test with. Even several instances per browser. The Protractor config file is named protractor.conf.json.

If you wish to test for more than one browser at once, replace the capabilities variable with multiCapabilities, like below. If you only wish for once session to be ran at a time, add maxSessions into it also. This can be useful, if you don’t want any concurrency issues.

maxSessions: 1,
multiCapabilities: [{
 } , {
You can play with the other settings also if you’d like.

Supported browsers

  • Chrome
  • Firefox
  • Internet Explorer
  • Edge
  • Safari
  • Android – Chrome (I have not done e2e on phones yet)
  • iOS – Safari (I have not done e2e on phones yet)

Writing a test

For your tests you need two or more files in the root of or in sub folders in the e2e folder. A PO (Page object) file, representing the actions to perform on a page. Like click a button that contains the text search. And one file containing your test specification. This is the *.e2e-spec.ts file.

To my knowledge, your e2e tests can not acces your code directly. It interacts with your page by simulating a user.

Page Object

One of the ways you can find the elements on your page, is by using css selectors. Some useful imports would be browser, by, element and $. $ and element are basically the same, and work kinda like jQuery.

import { browser, by, element, $ } from 'protractor';

A element has several functions, and two of them are getText(), click() and sendKeys(string). Below you can see an example of a PO file.

export class LoginPage {
  navigateTo() {
    return browser.get('/login');

  login(username: string, password: string) {
    // Using $
    // Using element and by
    element(by.cssContainingText('button', 'Login')).click();

  getLoginErrorMessage() {
    return $('#the-login-error-message').getText();

  getLoginSuccessMessage() {
    return $('#the-login-success-message').getText();

The spesification / Scenario

The spec files use Jasmine, and you can see an example of one below. In some cases you wish to wait for an event for a specific time. To do this, you can use the browser.sleep(timeInMS) function.
import { LoginPage } from './_login.po';
import { browser } from 'protractor';
import {} from 'jasmine';

describe('Logging in', () => {
  let page: LoginPage;
  beforeEach(() => {
    side= new LoginPage();

  it('Can\'t login with wrong credentials', () => {
    page.login('BruceLee', 'Wrong password');
    // Waiting for response

        .toEqual('You shall not pass.');

  it('Is able to login with proper credentials', () => {
    page.login('JetLee', 'eeLteJ');
    // Waiting for response

  // In some cases you might want ignore the synchronization.
  // Logging in, has been one of those I've had to do so
    browser.ignoreSynchronization = true;

      .toEqual(`Currently logged in as: Jet Lee`);

Running the tests

To run your tests, simply run the ng e2e command in the terminal. It will complie the application, if all goes well you will see one or more browser windows appear in the background.

Useful commands

For updating the web drivers you can run the following command:

'ng e2e --webdriver-update' or 'ng e2e --wu'

Running one or more specific spec file / test:

ng2 e2e --specs=e2e/a-test.e2e-spec.ts
ng2 e2e --specs=e2e/_login.e2e-spec.ts --specs=e2e/another-test.e2e-spec.ts

Running one or more specific tests (not really a command):
In order to just run spesific describe or it blocks, you can do it by adding an f to the beginning of the it or describe function name. Alternatively you could add x to exclude that block.

fit('a description', => {
fdescribe('a description', () => {
    it('', () => {});
    it('', () => {});

When you have done that, these are the only function that will be ran when you run the e2e command.

ng2 e2e


Running the test for a spesific build environment

ng e2e --target production || development

If you wish to run a single command for testing your linting, unit tests, e2e tests and if a production build is successful. Try adding a script like this to your package.json‘s script section. The &&’s make it so that it won’t continue to the next test, if the previous one failed.

ng lint && ng test && ng e2e && ng build --prod

The end

Thank you for reading! If you have anything to add, or if I for got something or you’ve got suggestions on this topic, feel free to post them in the comments.


Update 24/4-18:
added fit and fdescribe
